Rationale of the GFG/GFH distributor

1，The lubrication oil delivered from the lubrication pump starts to push upward through the umbrella valve in the GFG/GFH distributor.

2，When the umbrella valve closes the central hole of the core rod, the piston is forced to rise against the spring force. Drain the lubrication oil previously stored in the upper chamber.

3，When the piston moves to the top of the upper chamber, the oil discharge is completed at the same time.

4，When the lubrication pump stops supplying oil, its pressure relief valve opens automatically, so that the pressure oil in the main oil pipe reset to the oil through the pressure relief valve. At this time, the system pressure drops, and the piston in the distributor begins to recover under the action of the spring. When the umbrella valve reposition to close the distributor and enters the oil, the piston presses the lubrication oil stored in the lower chamber to the upper chamber through the small hole of the core rod. , and the next fuel supply is also ready.

1,Oil volume indication: (notes: when oil volume values of all oiloutlets are identical, represented with one oil volume).

2,Example 1: GFG/GFH-05-03 means that the oil volume of the 1st,2nd, 3rd, 4th and 5th oil outlet of the GFG/GFH type 5-portdistributor is all 0.03mL/time.

3,Example 2: GFG/GFH-05-1209060303 means that the oil volumeof the 1st, 2nd, 3rd, 4th and 5th oil outlet of the GFG/GFH type5-port distributor is 0.12, 0.09, 0.06, 0.03, 0.03 mL/time respectively.

4,Example 3: GFG/GFH-05-09-S means that the oil volume of the1st, 2nd, 3rd, 4th, and 5th oil outlet of the GFG/GFH type 5-portdistributor is all 0.09mL/time, and one end of the oil inlet mainpipe is matched with a pipe and an official cap; The other end of theoil inlet pipe is fitted with a plug.

5,Applicable ambient temperature:-10°C to 50°C.
